FCJ factory GYFTA Non-Metallic Strength Member Non-Armored Fiber Optical Cable
- group name
- Duct Fiber Optic Cables
- Min Order
- 1 kilometer
- brand name
- FCJ Fiber Optic Products Manufacturer
- model
- GYFTA Non-armored
- Nearest port for product export
- shanghai, Ningbo, Shenzhen, Guangzhou
- Delivery clauses under the trade mode
- FOB, CIF, EXW, Express Delivery
- Acceptable payment methods
- T/T, L/C, Credit Card, PayPal, Westem Union
- update time
- Fri, 22 Nov 2024 00:55:43 GMT
Paramtents
Certification RoHS, UL, CE, ISO9001, VDE, CCC
Brand Fcj Opto Tech
Sheath Material PE
Cable Application Aerial
Loose Tube Type PBT Central Tube Type
Transport Package Wooden Drum and Carton
Specification 2KM, 3KM
HS Code 8544700000
Service Life More Than 30years
Working Temp. -40~+60 Centigrade
Packging & Delivery
-
Min Order1 kilometer
Briefing
The cable put the fiber in the PBT loose tube,and one FRP as central strengthen member.
Detailed
Description
The GYFTA with Non-Metallic FRP cable structure is put the ф250μm colored fiber in the PBT loose tube, and one FRP as central strengthen member, Cable surface is extruded with a PE outer sheath.
Characteristics
· Good mechanical and temperature performance
· High strength loose tube that is hydrolysis resistant
· Special tube filling compound ensure a critical protection of fiber
· Specially designed compact structure is good at preventing loose tubes from shrinking
· PE sheath protects cable from ultraviolet radiation
· The following measures are taken to ensure the cable watertight:
- Single Fiber Reinforced Plastic as the central strength member
- Loose tube filling compound
- 100% cable core filling
- APL moisture barrier
· High strength loose tube that is hydrolysis resistant
· Special tube filling compound ensure a critical protection of fiber
· Specially designed compact structure is good at preventing loose tubes from shrinking
· PE sheath protects cable from ultraviolet radiation
· The following measures are taken to ensure the cable watertight:
- Single Fiber Reinforced Plastic as the central strength member
- Loose tube filling compound
- 100% cable core filling
- APL moisture barrier
Standards
GYFTA cable complies with Standard YD/T 901-2001as well as IEC 60794-1.
Optical Characteristics
G.652 | G.655 | 50/125μm | 62.5/125μm | ||
Attenuation (+20℃) | @850nm | ≤3.0 dB/km | ≤3.0 dB/km | ||
@1300nm | ≤1.0 dB/km | ≤1.0 dB/km | |||
@1310nm | ≤0.36 dB/km | ≤0.40 dB/km | |||
@1550nm | ≤0.22 dB/km | ≤0.23dB/km | |||
Bandwidth （Class A） | @850nm | ≥500 MHz·km | ≥200 MHz·km | ||
@1300nm | ≥1000 MHz·km | ≥600 MHz·km | |||
Numerical aperture | 0.200±0.015NA | 0.275±0.015NA | |||
Cable Cutoff Wavelength | ≤1260nm | ≤1480nm | |||
Technical Parameters
Fiber count | Structure | Fibers per tube | Loose tube diamete R (mm) | / CSM diameter/pad diameter (mm) | Thickness of outer jacket (mm) | Cable diameter (mm) | Cable weight (kg/km) |
| 4 | 1+6 | 4 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 84 |
| 6 | 1+6 | 6 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 84 |
| 8 | 1+6 | 4 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 84 |
| 12 | 1+6 | 6 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 84 |
| 18 | 1+6 | 6 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 85 |
| 24 | 1+6 | 6 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 85 |
| 30 | 1+6 | 6 | 1.8±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 86 |
| 36 | 1+6 | 6 | 1.8 ±0.1 | 2.2 /2.2 | 1.6±0.1 | 10.0±0.5 | 86 |
| 48 | 1+6 | 12 | 2.0±0.1 | 2.3 /2.3 | 1.6±0.1 | 10.7±0.5 | 96 |
